| Part Number | NX3P1107UKZ | NX3P1108UKZ |
|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Active |
| Switch Type | General Purpose | General Purpose |
| Number of Outputs | 1 | 1 |
| Ratio - Input:Output | 1:1 | 1:1 |
| Output Configuration | High Side | High Side |
| Output Type | P-Channel | P-Channel |
| Interface | On/Off | On/Off |
| Voltage - Load | 0.9V ~ 3.6V | 0.9V ~ 3.6V |
| Voltage - Supply (Vcc/Vdd) | Not Required | Not Required |
| Current - Output (Max) | 1.5A | 1.5A |
| Rds On (Typ) | 34mOhm | 34mOhm |
| Input Type | - | - |
| Features | Slew Rate Controlled | Load Discharge, Slew Rate Controlled |
| Fault Protection | - | - |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | 4-WLCSP (0.96x0.96) | 4-WLCSP (0.96x0.96) |
| Package / Case | 4-UFBGA, WLCSP | 4-UFBGA, WLCSP |
