| Part Number | MRF5S21100HR5 | MRF5S21130HR5 | MRF6S21100HR5 | MRF5S21100HR3 |
|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Transistor Type | LDMOS | LDMOS | LDMOS | LDMOS |
| Frequency | 2.16GHz ~ 2.17GHz | 2.11GHz ~ 2.17GHz | 2.11GHz ~ 2.17GHz | 2.16GHz ~ 2.17GHz |
| Gain | 13.5dB | 13.5dB | 15.9dB | 13.5dB |
| Voltage - Test | 28 V | 28 V | 28 V | 28 V |
| Current Rating (Amps) | - | - | - | - |
| Noise Figure | - | - | - | - |
| Current - Test | 1.05 A | 1.2 A | 950 mA | 1.05 A |
| Power - Output | 23W | 28W | 23W | 23W |
| Voltage - Rated | 65 V | 65 V | 68 V | 65 V |
| Package / Case | SOT-957A | SOT-957A | SOT-957A | SOT-957A |
| Supplier Device Package | NI-780H-2L | NI-880H-2L | NI-780H-2L | NI-780H-2L |
