| Part Number | MPC8360ECVVAJDGA | MPC8360CVVAJDGA | MPC8360ECVVAJDG |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| Core Processor | PowerPC e300 | PowerPC e300 | PowerPC e300 |
| Number of Cores/Bus Width | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit |
| Speed | 533MHz | 533MHz | 533MHz |
| Co-Processors/DSP | Communications; QUICC Engine, Security; SEC | Communications; QUICC Engine | Communications; QUICC Engine, Security; SEC |
| RAM Controllers | DDR, DDR2 | DDR, DDR2 | DDR, DDR2 |
| Graphics Acceleration | No | No | No |
| Display & Interface Controllers | - | - | - |
| Ethernet | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) |
| SATA | - | - | - |
| USB | USB 1.x (1) | USB 1.x (1) | USB 1.x (1) |
| Voltage - I/O | 1.8V, 2.5V, 3.3V | 1.8V, 2.5V, 3.3V | 1.8V, 2.5V, 3.3V |
| Operating Temperature | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) | -40°C ~ 105°C (TA) |
| Security Features | Cryptography, Random Number Generator | - | Cryptography, Random Number Generator |
| Package / Case | 740-LBGA | 740-LBGA | 740-LBGA |
| Supplier Device Package | 740-TBGA (37.5x37.5) | 740-TBGA (37.5x37.5) | 740-TBGA (37.5x37.5) |
