| Part Number | MIMX8MN3CVTIZAA | MIMX8MN4CVTIZAA | MIMX8MN5CVTIZAA | MIMX8MN6CVTIZAA | MIMX8MN1CVTIZAA | MIMX8MN3CVPIZAA |
|---|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete | Active |
| Core Processor | ARM® Cortex®-A53 | ARM® Cortex®-A53 | ARM® Cortex®-A53 | ARM® Cortex®-A53 | ARM® Cortex®-A53 | ARM® Cortex®-A53 |
| Number of Cores/Bus Width | 2 Core, 64-Bit | 2 Core, 64-Bit | 4 Core, 64-Bit | 4 Core, 64-Bit | 1 Core, 64-Bit | 2 Core, 64-Bit |
| Speed | 1.4GHz | 1.4GHz | 1.4GHz | 1.4GHz | 1.4GHz | 1.4GHz |
| Co-Processors/DSP | ARM® Cortex®-M7 | ARM® Cortex®-M7 | ARM® Cortex®-M7 | ARM® Cortex®-M7 | ARM® Cortex®-M7 | ARM® Cortex®-M7 |
| RAM Controllers | DDR3L, DDR4, LPDDR4 | DDR3L, DDR4, LPDDR4 | DDR3L, DDR4, LPDDR4 | DDR3L, DDR4, LPDDR4 | DDR3L, DDR4, LPDDR4 | DDR3L, DDR4, LPDDR4 |
| Graphics Acceleration | Yes | Yes | Yes | Yes | Yes | Yes |
| Display & Interface Controllers | LCD, MIPI-CSI, MIPI-DSI | LCD, MIPI-CSI, MIPI-DSI | LCD, MIPI-CSI, MIPI-DSI | LCD, MIPI-CSI, MIPI-DSI | LCD, MIPI-CSI, MIPI-DSI | LCD, MIPI-CSI, MIPI-DSI |
| Ethernet | GbE | GbE | GbE | GbE | GbE | GbE |
| SATA | - | - | - | - | - | - |
| USB | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) | USB 2.0 + PHY (2) |
| Voltage - I/O | - | - | - | - | - | - |
| Operating Temperature | -40°C ~ 105°C (TJ) | -40°C ~ 105°C (TJ) | -40°C ~ 105°C (TJ) | -40°C ~ 105°C (TJ) | -40°C ~ 105°C (TJ) | -40°C ~ 105°C (TJ) |
| Security Features | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS | ARM TZ, CAAM, HAB, OCRAM, RDC, SJC, SNVS |
| Package / Case | 486-LFBGA, FCBGA | 486-LFBGA, FCBGA | 486-LFBGA, FCBGA | 486-LFBGA, FCBGA | 486-LFBGA, FCBGA | 306-TFBGA |
| Supplier Device Package | 486-LFBGA (14x14) | 486-LFBGA (14x14) | 486-LFBGA (14x14) | 486-LFBGA (14x14) | 486-LFBGA (14x14) | 306-TFBGA (11x11) |
