| Part Number | MCIMX6X4AVM08AB | MCIMX6X4CVM08AB | MCIMX6X4AVM08AC | MCIMX6X4AVM08ABR |
|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Active | Active | Active | Active |
| Core Processor | ARM® Cortex®-A9, ARM® Cortex®-M4 | ARM® Cortex®-A9, ARM® Cortex®-M4 | ARM® Cortex®-A9, ARM® Cortex®-M4 | ARM® Cortex®-A9, ARM® Cortex®-M4 |
| Number of Cores/Bus Width | 2 Core, 32-Bit | 2 Core, 32-Bit | 2 Core, 32-Bit | 2 Core, 32-Bit |
| Speed | 200MHz, 800MHz | 200MHz, 800MHz | 200MHz, 800MHz | 200MHz, 800MHz |
| Co-Processors/DSP | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE | Multimedia; NEON™ MPE |
| RAM Controllers | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 |
| Graphics Acceleration | Yes | Yes | Yes | Yes |
| Display & Interface Controllers | Keypad, LCD, LVDS | Keypad, LCD, LVDS | Keypad, LCD, LVDS | Keypad, LCD, LVDS |
| Ethernet | 10/100/1000Mbps (2) | 10/100/1000Mbps (2) | 10/100/1000Mbps (2) | 10/100/1000Mbps (2) |
| SATA | - | - | - | - |
| USB | USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2) | USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2) | USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2) | USB 2.0 + PHY (1), USB 2.0 OTG + PHY (2) |
| Voltage - I/O | 1.8V, 2.5V, 2.8V, 3.15V | 1.8V, 2.5V, 2.8V, 3.15V | 1.8V, 2.5V, 2.8V, 3.15V | 1.8V, 2.5V, 2.8V, 3.15V |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 105°C (TA) | -40°C ~ 125°C (TJ) | -40°C ~ 125°C (TJ) |
| Security Features | A-HAB, ARM TZ, CAAM, CSU, SNVS, System JTAG, TVDECODE | A-HAB, ARM TZ, CAAM, CSU, SNVS, System JTAG, TVDECODE | A-HAB, ARM TZ, CAAM, CSU, SNVS, System JTAG, TVDECODE | A-HAB, ARM TZ, CAAM, CSU, SNVS, System JTAG, TVDECODE |
| Package / Case | 529-LFBGA | 529-LFBGA | 529-LFBGA | 529-LFBGA |
| Supplier Device Package | 529-MAPBGA (19x19) | 529-MAPBGA (19x19) | 529-MAPBGA (19x19) | 529-MAPBGA (19x19) |
