Please send RFQ , we will respond immediately.
| Part Number | MCIMX6S5DVM10AB | MCIMX6S5DVM10AC | MCIMX6S5EVM10AB | MCIMX6U5DVM10AB | MCIMX6S5DVM10ABR | MCIMX6S5DVM10AD |
|---|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Not For New Designs | Active | Not For New Designs | Not For New Designs | Not For New Designs | Active |
| Core Processor | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 | ARM® Cortex®-A9 |
| Number of Cores/Bus Width | 1 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit | 2 Core, 32-Bit | 1 Core, 32-Bit | 1 Core, 32-Bit |
| Speed | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz |
| Co-Processors/DSP | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD |
| RAM Controllers | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 | LPDDR2, LVDDR3, DDR3 |
| Graphics Acceleration | Yes | Yes | Yes | Yes | Yes | Yes |
| Display & Interface Controllers | Keypad, LCD | Keypad, LCD | Keypad, LCD | Keypad, LCD | Keypad, LCD | Keypad, LCD |
| Ethernet | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) | 10/100/1000Mbps (1) |
| SATA | - | - | - | - | - | - |
| USB | USB 2.0 + PHY (4) | USB 2.0 + PHY (4) | USB 2.0 + PHY (4) | USB 2.0 + PHY (4) | USB 2.0 + PHY (4) | USB 2.0 + PHY (4) |
| Voltage - I/O | 1.8V, 2.5V, 2.8V, 3.3V | 1.8V, 2.5V, 2.8V, 3.3V | 1.8V, 2.5V, 2.8V, 3.3V | 1.8V, 2.5V, 2.8V, 3.3V | 1.8V, 2.5V, 2.8V, 3.3V | 1.8V, 2.5V, 2.8V, 3.3V |
| Operating Temperature | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | -20°C ~ 105°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) | 0°C ~ 95°C (TJ) |
| Security Features | ||||||
| Package / Case | 624-LFBGA | 624-LFBGA | 624-LFBGA | 624-LFBGA | 624-LFBGA | 624-LFBGA |
| Supplier Device Package | 624-MAPBGA (21x21) | 624-MAPBGA (21x21) | 624-MAPBGA (21x21) | 624-MAPBGA (21x21) | 624-MAPBGA (21x21) | 624-MAPBGA (21x21) |
