Please send RFQ , we will respond immediately.
| Part Number | MCIMX537CVP8C2R2 | MCIMX537CVV8C2R2 |
|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. |
| Product Status | Active | Obsolete |
| Core Processor | ARM® Cortex®-A8 | ARM® Cortex®-A8 |
| Number of Cores/Bus Width | 1 Core, 32-Bit | 1 Core, 32-Bit |
| Speed | 800MHz | 800MHz |
| Co-Processors/DSP | Multimedia; NEON™ SIMD | Multimedia; NEON™ SIMD |
| RAM Controllers | LPDDR2, DDR2, DDR3 | LPDDR2, DDR2, DDR3 |
| Graphics Acceleration | Yes | Yes |
| Display & Interface Controllers | Keypad, LCD, LVDS | Keypad, LCD |
| Ethernet | 10/100Mbps (1) | 10/100Mbps (1) |
| SATA | SATA 1.5Gbps (1) | SATA 1.5Gbps (1) |
| USB | USB 2.0 (2), USB 2.0 + PHY (1), USB 2.0 OTG + PHY (1) | USB 2.0 (2), USB 2.0 + PHY (2) |
| Voltage - I/O | 1.3V, 1.8V, 2.775V, 3.3V | 1.3V, 1.8V, 2.775V, 3.3V |
| Operating Temperature | -40°C ~ 125°C (TJ) | -40°C ~ 85°C (TA) |
| Security Features | ||
| Package / Case | 529-FBGA | 529-FBGA |
| Supplier Device Package | 529-FBGA (19x19) | 529-FBGA (19x19) |
