Please send RFQ , we will respond immediately.
| Part Number | MCF52211CVM80 | MCF52221CVM80 | MCF52211CVM80J |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | Freescale Semiconductor | NXP USA Inc. |
| Product Status | Obsolete | Active | Obsolete |
| Core Processor | Coldfire V2 | Coldfire V2 | Coldfire V2 |
| Core Size | 32-Bit Single-Core | 32-Bit Single-Core | 32-Bit Single-Core |
| Speed | 80MHz | 80MHz | 80MHz |
| Connectivity | I²C, SPI, UART/USART, USB OTG | I²C, SPI, UART/USART, USB OTG | I²C, SPI, UART/USART, USB OTG |
| Peripherals | DMA, LVD, POR, PWM, WDT | DMA, LVD, POR, PWM, WDT | DMA, LVD, POR, PWM, WDT |
| Number of I/O | 55 | 56 | 55 |
| Program Memory Size | 128KB (128K x 8) | 128KB (128K x 8) | 128KB (128K x 8) |
| Program Memory Type | Flash | Flash | Flash |
| EEPROM Size | - | - | - |
| RAM Size | 16K x 8 | 16K x 8 | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V |
| Data Converters | A/D 8x12b | A/D 8x12b | A/D 8x12b |
| Oscillator Type | Internal | Internal | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 81-LBGA | 81-LBGA | 81-LBGA |
| Supplier Device Package | 81-MAPBGA (10x10) | 81-MAPBGA (10x10) | 81-MAPBGA (10x10) |
