| Part Number | LPC2470FET208,551 | LPC2478FET208,551 | LPC2420FET208,551 | LPC2460FET208,551 |
|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs |
| Core Processor | ARM7® | ARM7® | ARM7® | ARM7® |
| Core Size | 16/32-Bit | 16/32-Bit | 16/32-Bit | 16/32-Bit |
| Speed | 72MHz | 72MHz | 72MHz | 72MHz |
| Connectivity | CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG | EBI/EMI, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG | CANbus, EBI/EMI, Ethernet, I²C, Microwire, Memory Card, SPI, SSI, SSP, UART/USART, USB OTG |
| Peripherals | Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, LCD, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT | Brown-out Detect/Reset, DMA, I²S, POR, PWM, WDT |
| Number of I/O | 160 | 160 | 160 | 160 |
| Program Memory Size | - | 512KB (512K x 8) | - | - |
| Program Memory Type | ROMless | Flash | ROMless | ROMless |
| EEPROM Size | - | - | - | - |
| RAM Size | 98K x 8 | 96K x 8 | 82K x 8 | 96K x 8 |
| Voltage - Supply (Vcc/Vdd) | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V | 3V ~ 3.6V |
| Data Converters | A/D 8x10b; D/A 1x10b | A/D 8x10b; D/A 1x10b | A/D 8x10b; D/A 1x10b | A/D 8x10b; D/A 1x10b |
| Oscillator Type | Internal | Internal | Internal | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 208-TFBGA | 208-TFBGA | 208-TFBGA | 208-TFBGA |
| Supplier Device Package | 208-TFBGA (15x15) | 208-TFBGA (15x15) | 208-TFBGA (15x15) | 208-TFBGA (15x15) |
