| Part Number | LPC2220FET144/G,51 | LPC2220FET144/G551 | LPC2220FET144/G,55 |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Not For New Designs | Active | Not For New Designs |
| Core Processor | ARM7® | ARM7® | ARM7® |
| Core Size | 16/32-Bit | 16/32-Bit | 16/32-Bit |
| Speed | 75MHz | 75MHz | 75MHz |
| Connectivity | EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART | EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART | EBI/EMI, I²C, Microwire, SPI, SSI, SSP, UART/USART |
| Peripherals | POR, PWM, WDT | POR, PWM, WDT | POR, PWM, WDT |
| Number of I/O | 76 | 76 | 76 |
| Program Memory Size | - | - | - |
| Program Memory Type | ROMless | ROMless | ROMless |
| EEPROM Size | - | - | - |
| RAM Size | 64K x 8 | 64K x 8 | 64K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.65V ~ 3.6V | 1.65V ~ 3.6V | 1.65V ~ 3.6V |
| Data Converters | A/D 8x10b | A/D 8x10b | A/D 8x10b |
| Oscillator Type | Internal | Internal | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 144-TFBGA | 144-TFBGA | 144-TFBGA |
| Supplier Device Package | 144-TFBGA (12x12) | 144-TFBGA (12x12) | 144-TFBGA (12x12) |
