| Part Number | JN5139-001-M/02R1V | JN5139-Z01-M/02R1V | JN5139-001-M/01R1V |
|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete |
| RF Family/Standard | 802.15.4 | 802.15.4 | 802.15.4 |
| Protocol | Zigbee® | Zigbee® | Zigbee® |
| Modulation | - | - | - |
| Frequency | 2.4GHz | 2.4GHz | 2.4GHz |
| Data Rate | - | - | - |
| Power - Output | 19dBm | 19dBm | 2.5dBm |
| Sensitivity | -100dBm | -100dBm | -96dBm |
| Serial Interfaces | I²C, SPI, UART | I²C, SPI, UART | I²C, SPI, UART |
| Antenna Type | Antenna Not Included, SMA | Antenna Not Included, SMA | Antenna Not Included, SMA |
| Utilized IC / Part | - | - | - |
| Memory Size | 192kB ROM, 96kB RAM | 192kB ROM, 96kB RAM | 192kB ROM, 96kB RAM |
| Voltage - Supply | 2.2V ~ 3.6V | 2.2V ~ 3.6V | 2.2V ~ 3.6V |
| Current - Receiving | 45mA | 45mA | 37mA |
| Current - Transmitting | 125mA | 125mA | 37mA |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Package / Case | Module | Module | Module |
