| Part Number | BUK7Y21-40E | BUK7Y21-40EX |
|---|---|---|
| Manufacturer | NXP USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active |
| FET Type | - | N-Channel |
| Technology | - | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | - | 40 V |
| Current - Continuous Drain (Id) @ 25°C | - | 33A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 10V |
| Rds On (Max) @ Id, Vgs | - | 21mOhm @ 10A, 10V |
| Vgs(th) (Max) @ Id | - | 4V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - | 10 nC @ 10 V |
| Vgs (Max) | - | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 617 pF @ 25 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 45W (Tc) |
| Operating Temperature | - | -55°C ~ 175°C (TJ) |
| Mounting Type | - | Surface Mount |
| Supplier Device Package | - | LFPAK56, Power-SO8 |
| Package / Case | - | SC-100, SOT-669 |
