| Part Number | BGU7064,518 | BGU7061,518 | BGU7062,518 | BGU7063,518 |
|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Last Time Buy | Obsolete | Obsolete |
| Frequency | - | 800MHz ~ 950MHz | 1.71GHz~1.785GHz | 1.92GHz ~ 1.98GHz |
| P1dB | - | -13dBm | -14dBm | -12.5dBm |
| Gain | 35dB | 37dB | 37dB | 37.5dB |
| Noise Figure | 0.9dB | 0.78dB | 0.85dB | 0.9dB |
| RF Type | GSM, LTE, WCDMA, WiMAX | Cellular | Cellular | Cellular |
| Voltage - Supply | 5V | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 4.75V ~ 5.25V |
| Current - Supply | - | 200mA | 220mA | 230mA |
| Test Frequency | - | 800MHz ~ 950MHz | 1.75GHz | 1.95GHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 16-LQFN Exposed Pad | 16-LQFN Exposed Pad | 16-LQFN Exposed Pad | 16-LQFN Exposed Pad |
| Supplier Device Package | 16-HLQFN (8x8) | 16-HLQFN (8x8) | 16-HLQFN (8x8) | 16-HLQFN (8x8) |
