Please send RFQ , we will respond immediately.
| Part Number | BGS8L5X | BGS8U5X | BGS8C5X | BGS8H5X | BGS8L2X |
|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Last Time Buy | Active | Obsolete | Obsolete | Active |
| Frequency | 703MHz ~ 960MHz | 3.4GHz ~ 3.8GHz | 5.15GHz ~ 5.85GHz | 1.425GHz ~ 2.69GHz | 728MHz ~ 960MHz |
| P1dB | 6dBm | 11dBm | - | 8.5dBm | - |
| Gain | 13.6dB | 15.5dB | 15dB | 13.1dB | 13dB |
| Noise Figure | 0.7dB | 1dB | 1.25dB | 0.75dB | 0.85dB |
| RF Type | Cellular, LTE | Cellular, LTE | Cellular, LTE | Cellular, LTE | - |
| Voltage - Supply | 1.5V ~ 3.1V | 1.5V ~ 3.1V | 1.5V ~ 3.1V | 1.5V ~ 3.1V | 1.5V ~ 3.1V |
| Current - Supply | 4.5mA | 4.5mA | 4.5mA | 4.5mA | 5.2mA |
| Test Frequency | - | - | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 6-XFDFN | 6-XFDFN | 6-XFDFN | 6-XFDFN | 6-XFDFN |
| Supplier Device Package | 6-XSON (1.1x0.7) | 6-XSON (1.1x0.7) | 6-XSON (1.1x0.7) | 6-XSON (1.1x0.7) | 6-XSON (1.1x0.7) |
