NXP USA Inc.-74HCT04DB-Q100118 - Logic - Gates and Inverters Product Specifications and Latest Quotes

Logic Type:	Inverter
Number of Circuits:	6
Number of Inputs:	1
Features:	-
Voltage - Supply:	4.5V ~ 5.5V
Current - Quiescent (Max):	2 µA
Current - Output High, Low:	4mA, 5.2mA
Logic Level - Low:	0.8V
Logic Level - High:	2V
Max Propagation Delay @ V, Max CL:	19ns @ 4.5V, 50pF
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Supplier Device Package:	14-SSOP
Package / Case:	14-SSOP (0.209", 5.30mm Width)

NXP USA Inc. 74HCT04DB-Q100118
