| Part Number | 74ABT374ADB,112 | 74ABT574ADB,112 | 74ABT374ADB,118 | 74ABT377ADB,112 | 74ABT374AD,112 |
|---|---|---|---|---|---|
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete | Obsolete |
| Function | Standard | Standard | Standard | Standard | Standard |
| Type | D-Type | D-Type | D-Type | D-Type | D-Type |
| Output Type | Tri-State, Non-Inverted | Tri-State, Non-Inverted | Tri-State, Non-Inverted | Non-Inverted | Tri-State, Non-Inverted |
| Number of Elements | 1 | 1 | 1 | 1 | 1 |
| Number of Bits per Element | 8 | 8 | 8 | 8 | 8 |
| Clock Frequency | 300 MHz | 400 MHz | 300 MHz | 250 MHz | 300 MHz |
| Max Propagation Delay @ V, Max CL | 4.9ns @ 5V, 50pF | 4.7ns @ 5V, 50pF | 4.9ns @ 5V, 50pF | 3.6ns @ 5V, 50pF | 4.9ns @ 5V, 50pF |
| Trigger Type | Positive Edge | Positive Edge | Positive Edge | Positive Edge | Positive Edge |
| Current - Output High, Low | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA | 32mA, 64mA |
| Voltage - Supply | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5V ~ 5.5V |
| Current - Quiescent (Iq) | 250 µA | 250 µA | 250 µA | 250 µA | 250 µA |
| Input Capacitance | 4 pF | 3 pF | 4 pF | 4 pF | 4 pF |
| Operating Temperature | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 20-SSOP | 20-SSOP | 20-SSOP | 20-SSOP | 20-SO |
| Package / Case | 20-SSOP (0.209", 5.30mm Width) | 20-SSOP (0.209", 5.30mm Width) | 20-SSOP (0.209", 5.30mm Width) | 20-SSOP (0.209", 5.30mm Width) | 20-SOIC (0.295", 7.50mm Width) |
