Nichicon-PSB2153220KHSD - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	0.22 µF
Tolerance:	±10%
Voltage Rating - AC:	650V
Voltage Rating - DC:	1500V (1.5kV)
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	4.4 mOhms
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Package / Case:	Radial - 4 Leads
Size / Dimension:	1.260" L x 0.709" W (32.00mm x 18.00mm)
Height - Seated (Max):	1.299" (33.00mm)
Termination:	PC Pins
Lead Spacing:	1.083" (27.50mm)
Applications:	High Frequency, Switching; High Pulse, DV/DT; Snubber
Ratings:	-
Features:	-

Nichicon PSB2153220KHSD
