Please send RFQ , we will respond immediately.
| Part Number | PPA2122470KJ | PPA2122470KG |
|---|---|---|
| Manufacturer | Nichicon | Nichicon |
| Product Status | Active | Active |
| Capacitance | 0.047 µF | 0.047 µF |
| Tolerance | ±10% | ±10% |
| Voltage Rating - AC | 550V | 550V |
| Voltage Rating - DC | 1200V (1.2kV) | 1200V (1.2kV) |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 19 mOhms | 17 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Axial | Axial |
| Size / Dimension | 0.394" Dia x 1.063" L (10.00mm x 27.00mm) | 0.394" Dia x 1.063" L (10.00mm x 27.00mm) |
| Height - Seated (Max) | - | - |
| Termination | PC Pins | PC Pins |
| Lead Spacing | - | - |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Ratings | - | - |
| Features | - | - |
