| Part Number | PPA2103100KJ | PPA2203100KJ | PPA2123100KJ | PPA2153100KJ | PPA2103150KJ | PPA2103100KG |
|---|---|---|---|---|---|---|
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon |
| Product Status | Active | Active | Active | Active | Active | Active |
| Capacitance | 0.1 µF | 0.1 µF | 0.1 µF | 0.1 µF | 0.15 µF | 0.1 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage Rating - AC | 525V | 650V | 550V | 600V | 525V | 525V |
| Voltage Rating - DC | 1000V (1kV) | 2000V (2kV) | 1200V (1.2kV) | 1500V (1.5kV) | 1000V (1kV) | 1000V (1kV) |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 11 mOhms | 8.4 mOhms | 10.7 mOhms | 9.6 mOhms | 8.2 mOhms | 10.2 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.492" Dia x 1.063" L (12.50mm x 27.00mm) | 0.433" Dia x 1.260" L (11.00mm x 32.00mm) | 0.984" Dia x 2.087" L (25.00mm x 53.00mm) | 0.551" Dia x 1.260" L (14.00mm x 32.00mm) | 0.591" Dia x 1.063" L (15.00mm x 27.00mm) | 0.492" Dia x 1.063" L (12.50mm x 27.00mm) |
| Height - Seated (Max) | - | - | - | - | - | - |
| Termination | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins |
| Lead Spacing | - | - | - | - | - | - |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Ratings | - | - | - | - | - | - |
| Features | - | - | - | - | - | - |
