| Part Number | PMB2124100KSR | PMB2154100KSR | PMB2124100KVR | PMB2124200KSR | PMB2124150KSR | PMB2124100KSP |
|---|---|---|---|---|---|---|
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon |
| Product Status | Active | Active | Active | Active | Active | Active |
| Capacitance | 1 µF | 1 µF | 1 µF | 2 µF | 1.5 µF | 1 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage Rating - AC | 630V | 650V | 630V | 630V | 630V | 630V |
| Voltage Rating - DC | 1200V (1.2kV) | 1500V (1.5kV) | 1200V (1.2kV) | 1200V (1.2kV) | 1200V (1.2kV) | 1200V (1.2kV) |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 2.7 mOhms | 2.5 mOhms | 2.7 mOhms | 2.4 mOhms | 2.1 mOhms | 2.7 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount |
| Package / Case | Rectangular Box | Rectangular Box | Rectangular Box | Rectangular Box | Rectangular Box | Rectangular Box |
| Size / Dimension | 1.673" L x 1.319" W (42.50mm x 33.50mm) | 1.673" L x 1.299" W (42.50mm x 33.00mm) | 1.673" L x 1.319" W (42.50mm x 33.50mm) | 2.264" L x 1.181" W (57.50mm x 30.00mm) | 1.673" L x 1.299" W (42.50mm x 33.00mm) | 1.673" L x 1.319" W (42.50mm x 33.50mm) |
| Height - Seated (Max) | 1.398" (35.50mm) | 1.772" (45.00mm) | 1.398" (35.50mm) | 1.772" (45.00mm) | 1.772" (45.00mm) | 1.398" (35.50mm) |
| Termination | Screw Terminals | Screw Terminals | Screw Terminals | Screw Terminals | Screw Terminals | Screw Terminals |
| Lead Spacing | - | - | - | - | - | - |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Ratings | - | - | - | - | - | - |
| Features | - | - | - | - | - | - |
