Please send RFQ , we will respond immediately.
| Part Number | PMB1854150KSP | PMB1854150KVP | PMB1854150KSR | PMB1854250KSP | PMB1854100KSP |
|---|---|---|---|---|---|
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon |
| Product Status | Active | Active | Active | Active | Active |
| Capacitance | 1.5 µF | 1.5 µF | 1.5 µF | 2.5 µF | 1 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage Rating - AC | 500V | 500V | 500V | 500V | 500V |
| Voltage Rating - DC | 850V | 850V | 850V | 850V | 850V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 2.2 mOhms | 2.2 mOhms | 2.2 mOhms | 1.9 mOhms | 2.7 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount | Chassis Mount |
| Package / Case | Rectangular Box | Rectangular Box | Rectangular Box | Rectangular Box | Rectangular Box |
| Size / Dimension | 1.673" L x 1.319" W (42.50mm x 33.50mm) | 1.673" L x 1.319" W (42.50mm x 33.50mm) | 1.673" L x 1.319" W (42.50mm x 33.50mm) | 1.673" L x 1.299" W (42.50mm x 33.00mm) | 1.673" L x 0.965" W (42.50mm x 24.50mm) |
| Height - Seated (Max) | 1.398" (35.50mm) | 1.398" (35.50mm) | 1.398" (35.50mm) | 1.772" (45.00mm) | 1.083" (27.50mm) |
| Termination | Screw Terminals | Screw Terminals | Screw Terminals | Screw Terminals | Screw Terminals |
| Lead Spacing | - | - | - | - | - |
| Applications | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber | High Frequency, Switching; High Pulse, DV/DT; Snubber |
| Ratings | - | - | - | - | - |
| Features | - | - | - | - | - |
