Nichicon-PMB1704470KFP - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	4.7 µF
Tolerance:	±10%
Voltage Rating - AC:	420V
Voltage Rating - DC:	700V
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	2.1 mOhms
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Chassis Mount
Package / Case:	Rectangular Box
Size / Dimension:	2.264" L x 1.378" W (57.50mm x 35.00mm)
Height - Seated (Max):	1.969" (50.00mm)
Termination:	Screw Terminals
Lead Spacing:	1.555" (39.50mm)
Applications:	High Frequency, Switching; High Pulse, DV/DT; Snubber
Ratings:	-
Features:	-

Nichicon PMB1704470KFP
