Please send RFQ , we will respond immediately.
| Part Number | PHC1604300KN | PHC1604330KN | PHC1704300KN | PHC1604500KN | PHC1604400KN | PHC1604200KN |
|---|---|---|---|---|---|---|
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon |
| Product Status | Active | Active | Active | Active | Active | Active |
| Capacitance | 3 µF | 3.3 µF | 3 µF | 5 µF | 4 µF | 2 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage Rating - AC | 330V | 330V | 400V | 330V | 330V | 330V |
| Voltage Rating - DC | 600V | 600V | 700V | 600V | 600V | 600V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 4.2 mOhms | 4 mOhms | 6.1 mOhms | 6.3 mOhms | 3.6 mOhms | 5.3 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.866" Dia x 1.732" L (22.00mm x 44.00mm) | 0.906" Dia x 1.732" L (23.00mm x 44.00mm) | 1.063" Dia x 1.732" L (27.00mm x 44.00mm) | 1.083" Dia x 1.732" L (27.50mm x 44.00mm) | 1.004" Dia x 1.732" L (25.50mm x 44.00mm) | 0.709" Dia x 1.732" L (18.00mm x 44.00mm) |
| Height - Seated (Max) | - | - | - | - | - | - |
| Termination | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins |
| Lead Spacing | - | - | - | - | - | - |
| Applications | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching |
| Ratings | - | - | - | - | - | - |
| Features | - | - | - | - | - | - |
