Please send RFQ , we will respond immediately.
| Part Number | PHC1404100KJ | PHC1404300KJ | PHC1404200KJ | PHC1404400KJ | PHC1404150KJ | PHC1704100KJ | PHC1604100KJ | PHC1404100KG |
|---|---|---|---|---|---|---|---|---|
| Manufacturer | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon | Nichicon |
| Product Status | Active | Active | Active | Active | Active | Active | Active | Active |
| Capacitance | 1 µF | 3 µF | 2 µF | 4 µF | 1.5 µF | 1 µF | 1 µF | 1 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% | ±10% |
| Voltage Rating - AC | 250V | 250V | 250V | 250V | 250V | 400V | 330V | 250V |
| Voltage Rating - DC | 400V | 400V | 400V | 400V | 400V | 700V | 600V | 400V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 6.7 mOhms | 3.8 mOhms | 4.6 mOhms | 3.3 mOhms | 5.6 mOhms | 4.5 mOhms | 6.1 mOhms | 5.8 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Axial | Axial | Axial | Axial | Axial | Axial | Axial | Axial |
| Size / Dimension | 0.433" Dia x 1.260" L (11.00mm x 32.00mm) | 0.748" Dia x 1.260" L (19.00mm x 32.00mm) | 0.610" Dia x 1.260" L (15.50mm x 32.00mm) | 0.866" Dia x 1.260" L (22.00mm x 32.00mm) | 0.610" Dia x 1.063" L (15.50mm x 27.00mm) | 0.768" Dia x 1.260" L (19.50mm x 32.00mm) | 0.610" Dia x 1.260" L (15.50mm x 32.00mm) | 0.512" Dia x 1.063" L (13.00mm x 27.00mm) |
| Height - Seated (Max) | - | - | - | - | - | - | - | - |
| Termination | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins | PC Pins |
| Lead Spacing | - | - | - | - | - | - | - | - |
| Applications | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching | High Frequency, Switching |
| Ratings | - | - | - | - | - | - | - | - |
| Features | - | - | - | - | - | - | - | - |
