Nichicon-MWS2402330KJ - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	0.033 µF
Tolerance:	±10%
Voltage Rating - AC:	750V
Voltage Rating - DC:	4000V (4kV)
Dielectric Material:	Polyester, Metallized
ESR (Equivalent Series Resistance):	-
Operating Temperature:	-55°C ~ 105°C
Mounting Type:	Through Hole
Package / Case:	Axial
Size / Dimension:	0.787" Dia x 1.260" L (20.00mm x 32.00mm)
Height - Seated (Max):	-
Termination:	PC Pins
Lead Spacing:	-
Applications:	General Purpose
Ratings:	-
Features:	-

Nichicon MWS2402330KJ
