| Part Number | MHBS355900KRST | MHBS355900KRSD |
|---|---|---|
| Manufacturer | Nichicon | Nichicon |
| Product Status | Active | Active |
| Capacitance | 90 µF | 90 µF |
| Tolerance | ±10% | ±10% |
| Voltage Rating - AC | 240V | 240V |
| Voltage Rating - DC | 575V | 575V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | 2.9 mOhms | 3.1 mOhms |
| Operating Temperature | -40°C ~ 85°C | -40°C ~ 85°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial - 6 Leads | Radial - 4 Leads |
| Size / Dimension | 2.264" L x 1.496" W (57.50mm x 38.00mm) | 2.264" L x 1.496" W (57.50mm x 38.00mm) |
| Height - Seated (Max) | 2.264" (57.50mm) | 2.264" (57.50mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 2.067" (52.50mm) | 2.067" (52.50mm) |
| Applications | DC Link, DC Filtering; High Frequency, Switching | DC Link, DC Filtering; High Frequency, Switching |
| Ratings | - | - |
| Features | - | - |
