Nichicon-MHBS354470KHL - Film Capacitors Product Specifications and Latest Quotes

Capacitance:	4.7 µF
Tolerance:	±10%
Voltage Rating - AC:	240V
Voltage Rating - DC:	575V
Dielectric Material:	Polypropylene (PP), Metallized
ESR (Equivalent Series Resistance):	11.6 mOhms
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Through Hole
Package / Case:	Radial
Size / Dimension:	1.260" L x 0.512" W (32.00mm x 13.00mm)
Height - Seated (Max):	0.866" (22.00mm)
Termination:	PC Pins
Lead Spacing:	1.083" (27.50mm)
Applications:	DC Link, DC Filtering; High Frequency, Switching
Ratings:	-
Features:	-

Nichicon MHBS354470KHL
