| Part Number | MABA034400KIL | MABA034400KHL |
|---|---|---|
| Manufacturer | Nichicon | Nichicon |
| Product Status | Active | Active |
| Capacitance | 4 µF | 4 µF |
| Tolerance | ±10% | ±10% |
| Voltage Rating - AC | 250V | 250V |
| Voltage Rating - DC | 500V | 500V |
| Dielectric Material | Polypropylene (PP), Metallized | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - | - |
| Operating Temperature | -40°C ~ 100°C | -40°C ~ 100°C |
| Mounting Type | Through Hole | Through Hole |
| Package / Case | Radial | Radial |
| Size / Dimension | 1.555" L x 0.591" W (39.50mm x 15.00mm) | 1.260" L x 0.709" W (32.00mm x 18.00mm) |
| Height - Seated (Max) | 1.024" (26.00mm) | 1.299" (33.00mm) |
| Termination | PC Pins | PC Pins |
| Lead Spacing | 1.378" (35.00mm) | 1.083" (27.50mm) |
| Applications | Motor Run | Motor Run |
| Ratings | - | - |
| Features | - | - |
