| Part Number | PMZB320UPE,315 | PMZB350UPE,315 |
|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active |
| FET Type | - | P-Channel |
| Technology | - | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | - | 20 V |
| Current - Continuous Drain (Id) @ 25°C | - | 1A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | 1.8V, 4.5V |
| Rds On (Max) @ Id, Vgs | - | 450mOhm @ 300mA, 4.5V |
| Vgs(th) (Max) @ Id | - | 950mV @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | - | 1.9 nC @ 4.5 V |
| Vgs (Max) | - | ±8V |
| Input Capacitance (Ciss) (Max) @ Vds | - | 127 pF @ 10 V |
| FET Feature | - | - |
| Power Dissipation (Max) | - | 360mW (Ta), 3.125W (Tc) |
| Operating Temperature | - | -55°C ~ 150°C (TJ) |
| Mounting Type | - | Surface Mount |
| Supplier Device Package | - | DFN1006B-3 |
| Package / Case | - | 3-XFDFN |
