| Part Number | PMEG1020EH,115 | PMEG1030EH,115 | PMEG1020EV,115 | PMEG1020EJ,115 | PMEG1020EA,115 |
|---|---|---|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | NXP Semiconductors | NXP Semiconductors | Nexperia USA Inc. |
| Product Status | Active | Active | Active | Active | Active |
| Diode Type | Schottky | Schottky | Schottky | Schottky | Schottky |
| Voltage - DC Reverse (Vr) (Max) | 10 V | 10 V | 10 V | 10 V | 10 V |
| Current - Average Rectified (Io) | 2A (DC) | 3A (DC) | 2A (DC) | 2A (DC) | 2A (DC) |
| Voltage - Forward (Vf) (Max) @ If | 460 mV @ 2 A | 530 mV @ 3 A | 460 mV @ 2 A | 460 mV @ 2 A | 460 mV @ 2 A |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | - | - | - | - | - |
| Current - Reverse Leakage @ Vr | 3 mA @ 10 V | 3 mA @ 10 V | 3 mA @ 10 V | 3 mA @ 10 V | 3 mA @ 10 V |
| Capacitance @ Vr, F | 50pF @ 5V, 1MHz | 85pF @ 1V, 1MHz | 45pF @ 5V, 1MHz | 50pF @ 5V, 1MHz | 45pF @ 5V, 1MHz |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | SOD-123F | SOD-123F | SOT-563, SOT-666 | SC-90, SOD-323F | SC-76, SOD-323 |
| Supplier Device Package | SOD-123F | SOD-123F | SOT-666 | SOD-323F | SOD-323 |
| Operating Temperature - Junction | 150°C (Max) | 150°C (Max) | 150°C (Max) | 150°C (Max) | 150°C (Max) |
