| Part Number | NX138AKMYL | NX138BKMYL |
|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 270mA (Ta) | 380mA (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 10V | - |
| Rds On (Max) @ Id, Vgs | 4.2Ohm @ 190mA, 10V | 2.3Ohm @ 380mA, 10V |
| Vgs(th) (Max) @ Id | 1.5V @ 250µA | 1.5V @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 0.6 nC @ 10 V | 0.7 nC @ 10 V |
| Vgs (Max) | ±20V | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 15 pF @ 30 V | 20 pF @ 30 V |
| FET Feature | - | - |
| Power Dissipation (Max) | 340mW (Ta), 2.3W (Tc) | 380mW (Ta), 2.8W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | SOT-883 | SOT-883 |
| Package / Case | SC-101, SOT-883 | SC-101, SOT-883 |
