| Part Number | BUK6215-75C,118-NEX | BUK6211-75C,118-NEX |
|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active |
| FET Type | N-Channel | N-Channel |
| Technology | MOSFET (Metal Oxide) | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 75 V | 75 V |
| Current - Continuous Drain (Id) @ 25°C | 57A (Ta) | 74A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | - | - |
| Rds On (Max) @ Id, Vgs | 15mOhm @ 15A, 10V | 11mOhm @ 25A, 10V |
| Vgs(th) (Max) @ Id | 2.8V @ 1mA | 2.8V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | 61.8 nC @ 10 V | 81 nC @ 10 V |
| Vgs (Max) | ±16V | ±16V |
| Input Capacitance (Ciss) (Max) @ Vds | 3900 pF @ 25 V | 5251 pF @ 25 V |
| FET Feature | - | - |
| Power Dissipation (Max) | 128W (Ta) | 158W (Ta) |
| Operating Temperature | -55°C ~ 175°C (TJ) | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount | Surface Mount |
| Supplier Device Package | DPAK | DPAK |
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 | TO-252-3, DPak (2 Leads + Tab), SC-63 |
