| Part Number | 74HCT04PW,118 | 74HCT08PW,118 | 74HCT14PW,118 | 74HCT00PW,118 | 74HCT02PW,118 | 74HCT03PW,118 | 74HCT04PW,112 |
|---|---|---|---|---|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. | NXP Semiconductors | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active | Active | Active | Active | Active | Obsolete |
| Logic Type | Inverter | AND Gate | Inverter | - | NOR Gate | NAND Gate | Inverter |
| Number of Circuits | 6 | 4 | 6 | - | 4 | 4 | 6 |
| Number of Inputs | 1 | 2 | 1 | - | 2 | 2 | 1 |
| Features | - | - | Schmitt Trigger | - | - | Open Drain | - |
| Voltage - Supply | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5V ~ 5.5V | - | 4.5V ~ 5.5V | 4.5V ~ 5.5V | 4.5V ~ 5.5V |
| Current - Quiescent (Max) | 2 µA | 2 µA | 2 µA | - | 2 µA | 2 µA | 2 µA |
| Current - Output High, Low | 4mA, 4mA | 4mA, 4mA | 4mA, 4mA | - | 4mA, 4mA | -, 4mA | 4mA, 4mA |
| Logic Level - Low | 0.8V | 0.8V | 0.5V ~ 0.6V | - | 0.8V | 0.8V | 0.8V |
| Logic Level - High | 2V | 2V | 1.9V ~ 2.1V | - | 2V | 2V | 2V |
| Max Propagation Delay @ V, Max CL | 19ns @ 4.5V, 50pF | 24ns @ 4.5V, 50pF | 34ns @ 4.5V, 50pF | - | 19ns @ 4.5V, 50pF | 24ns @ 4.5V, 50pF | 19ns @ 4.5V, 50pF |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C | - | -40°C ~ 125°C | -40°C ~ 125°C | -40°C ~ 125°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | - | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 14-TSSOP | 14-TSSOP | 14-TSSOP | - | 14-TSSOP | 14-TSSOP | 14-TSSOP |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) | 14-TSSOP (0.173", 4.40mm Width) | 14-TSSOP (0.173", 4.40mm Width) | - | 14-TSSOP (0.173", 4.40mm Width) | 14-TSSOP (0.173", 4.40mm Width) | 14-TSSOP (0.173", 4.40mm Width) |
