Please send RFQ , we will respond immediately.
| Part Number | 74AUP1G74GN,115 | 74AUP1G74GT,115 | 74AUP1G74GS,115 | 74AUP1G74GF,115 |
|---|---|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. | NXP USA Inc. |
| Product Status | Active | Active | Active | Active |
| Function | Set(Preset) and Reset | Set(Preset) and Reset | Set(Preset) and Reset | Set(Preset) and Reset |
| Type | D-Type | D-Type | D-Type | D-Type |
| Output Type | Complementary | Complementary | Complementary | Complementary |
| Number of Elements | 1 | 1 | 1 | 1 |
| Number of Bits per Element | 1 | 1 | 1 | 1 |
| Clock Frequency | 315 MHz | 315 MHz | 315 MHz | 315 MHz |
| Max Propagation Delay @ V, Max CL | 5.8ns @ 3.3V, 30pF | 5.8ns @ 3.3V, 30pF | 5.8ns @ 3.3V, 30pF | 5.8ns @ 3.3V, 30pF |
| Trigger Type | Positive Edge | Positive Edge | Positive Edge | Positive Edge |
| Current - Output High, Low | 4mA, 4mA | 4mA, 4mA | 4mA, 4mA | 4mA, 4mA |
| Voltage - Supply | 0.8V ~ 3.6V | 0.8V ~ 3.6V | 0.8V ~ 3.6V | 0.8V ~ 3.6V |
| Current - Quiescent (Iq) | 500 nA | 500 nA | 500 nA | 500 nA |
| Input Capacitance | 0.6 pF | 0.6 pF | 0.6 pF | 0.6 pF |
| Operating Temperature | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Supplier Device Package | 8-XSON (1.2x1) | 8-XSON, SOT833-1 (1.95x1) | 8-XSON (1.35x1) | 8-XSON (1.35x1) |
| Package / Case | 8-XFDFN | 8-XFDFN | 8-XFDFN | 8-XFDFN |
