74AHC374PW,112
  • Share:

Nexperia USA Inc. 74AHC374PW,112

Manufacturer No:
74AHC374PW,112
Manufacturer:
Nexperia USA Inc.
Package:
Tube
Datasheet:
74AHC374PW,112 Datasheet
ECAD Model:
-
Description:
IC FF D-TYPE SNGL 8BIT 20TSSOP
Delivery:
Payment:
iso14001
iso45001
iso9001
iso13485

Product Attributes

Function:Standard
Type:D-Type
Output Type:Tri-State, Non-Inverted
Number of Elements:1
Number of Bits per Element:8
Clock Frequency:120 MHz
Max Propagation Delay @ V, Max CL:10.1ns @ 5V, 50pF
Trigger Type:Positive Edge
Current - Output High, Low:8mA, 8mA
Voltage - Supply:2V ~ 5.5V
Current - Quiescent (Iq):4 µA
Input Capacitance:3 pF
Operating Temperature:-40°C ~ 125°C (TA)
Mounting Type:Surface Mount
Supplier Device Package:20-TSSOP
Package / Case:20-TSSOP (0.173", 4.40mm Width)
0 Remaining View Similar

In Stock

-
138

Please send RFQ , we will respond immediately.

Similar Products

Part Number 74AHC374PW,112 74AHC574PW,112   74AHC74PW,112   74AHC374PW,118   74AHC377PW,112   74AHCT74PW,112
Manufacturer Nexperia USA Inc. NXP USA Inc. Nexperia USA Inc. Nexperia USA Inc. Nexperia USA Inc. Nexperia USA Inc.
Product Status Obsolete Active Obsolete Active Obsolete Obsolete
Function Standard Standard Set(Preset) and Reset Standard Standard Set(Preset) and Reset
Type D-Type D-Type D-Type D-Type D-Type D-Type
Output Type Tri-State, Non-Inverted Tri-State, Non-Inverted Complementary Tri-State, Non-Inverted Non-Inverted Complementary
Number of Elements 1 1 2 1 1 2
Number of Bits per Element 8 8 1 8 8 1
Clock Frequency 120 MHz 115 MHz 115 MHz 120 MHz 120 MHz 140 MHz
Max Propagation Delay @ V, Max CL 10.1ns @ 5V, 50pF 10.6ns @ 5V, 50pF 9.3ns @ 5V, 50pF 10.1ns @ 5V, 50pF 10.5ns @ 5V, 50pF 8.8ns @ 5V, 50pF
Trigger Type Positive Edge Positive Edge Positive Edge Positive Edge Positive Edge Positive Edge
Current - Output High, Low 8mA, 8mA 8mA, 8mA 8mA, 8mA 8mA, 8mA 8mA, 8mA 8mA, 8mA
Voltage - Supply 2V ~ 5.5V 2V ~ 5.5V 2V ~ 5.5V 2V ~ 5.5V 2V ~ 5.5V 4.5V ~ 5.5V
Current - Quiescent (Iq) 4 µA 4 µA 2 µA 4 µA 4 µA 2 µA
Input Capacitance 3 pF 3 pF 3 pF 3 pF 3 pF 3 pF
Operating Temperature -40°C ~ 125°C (TA) -40°C ~ 125°C (TA) -40°C ~ 125°C (TA) -40°C ~ 125°C (TA) -40°C ~ 125°C (TA) -40°C ~ 125°C (TA)
Mounting Type Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount Surface Mount
Supplier Device Package 20-TSSOP 20-TSSOP 14-TSSOP 20-TSSOP 20-TSSOP 14-TSSOP
Package / Case 20-TSSOP (0.173", 4.40mm Width) 20-TSSOP (0.173", 4.40mm Width) 14-TSSOP (0.173", 4.40mm Width) 20-TSSOP (0.173", 4.40mm Width) 20-TSSOP (0.173", 4.40mm Width) 14-TSSOP (0.173", 4.40mm Width)
