| Part Number | 1N4730A,133 | 1N4732A,133 | 1N4731A,133 | 1N4730A,113 |
|---|---|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | NXP USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active | Active | Active |
| Voltage - Zener (Nom) (Vz) | 3.9 V | 4.7 V | 4.3 V | 3.9 V |
| Tolerance | ±5% | ±5% | ±5% | ±5% |
| Power - Max | 1 W | 1 W | 1 W | 1 W |
| Impedance (Max) (Zzt) | 9 Ohms | 8 Ohms | 9 Ohms | 9 Ohms |
| Current - Reverse Leakage @ Vr | 50 µA @ 1 V | 10 µA @ 1 V | 10 µA @ 1 V | 50 µA @ 1 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 200 mA | 1.2 V @ 200 mA | 1.2 V @ 200 mA | 1.2 V @ 200 mA |
| Operating Temperature | -65°C ~ 200°C | -65°C ~ 200°C | -65°C ~ 200°C | -65°C ~ 200°C |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial | DO-204AL, DO-41, Axial |
| Supplier Device Package | DO-41 | DO-41 | DO-41 | DO-41 |
