Please send RFQ , we will respond immediately.
| Part Number | 1N4531,133 | 1N4531,143 | 1N4531133 | 1N4531,113 |
|---|---|---|---|---|
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. |
| Product Status | Active | Active | Active | Active |
| Diode Type | Standard | Standard | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) | 75 V | 75 V | 75 V | 75 V |
| Current - Average Rectified (Io) | 200mA (DC) | 200mA (DC) | - | 200mA (DC) |
| Voltage - Forward (Vf) (Max) @ If | 1 V @ 10 mA | 1 V @ 10 mA | 1 V @ 10 mA | 1 V @ 10 mA |
| Speed | Small Signal =< 200mA (Io), Any Speed | Small Signal =< 200mA (Io), Any Speed | - | Small Signal =< 200mA (Io), Any Speed |
| Reverse Recovery Time (trr) | 4 ns | 4 ns | 4 ns | 4 ns |
| Current - Reverse Leakage @ Vr | 25 nA @ 20 V | 25 nA @ 20 V | 25 nA @ 20 V | 25 nA @ 20 V |
| Capacitance @ Vr, F | 4pF @ 0V, 1MHz | 4pF @ 0V, 1MHz | 4pF @ 0V, 1MHz | 4pF @ 0V, 1MHz |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial | DO-204AG, DO-34, Axial |
| Supplier Device Package | DO-34 | DO-34 | DO-34 | DO-34 |
| Operating Temperature - Junction | 200°C (Max) | 200°C (Max) | 200°C (Max) | 200°C (Max) |
