| Part Number | TZY2Z2R5A001R00 | TZY2Z2R5AC01R00 | TZY2Z2R5A001B00 |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Obsolete | Obsolete | Obsolete |
| Capacitance Range | 0.65 ~ 2.5pF | 1 ~ 2.5pF | 0.65 ~ 2.5pF |
| Adjustment Type | Top | Top | Top |
| Voltage - Rated | 25 V | 25 V | 25 V |
| Dielectric Material | Ceramic | Ceramic | Ceramic |
| Q @ Freq | 200 @ 200MHz | 200 @ 200MHz | 200 @ 200MHz |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height - Seated (Max) | 0.049" (1.25mm) | 0.049" (1.25mm) | 0.049" (1.25mm) |
| Operating Temperature | -25°C ~ 85°C | -25°C ~ 85°C | -25°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Features | General Purpose | General Purpose | General Purpose |
