Please send RFQ , we will respond immediately.
| Part Number | TZV2Z030A110R00 | TZV2Z060A110R00 | TZV2Z030A110B00 |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Discontinued at Digi-Key | Discontinued at Digi-Key | Not For New Designs |
| Capacitance Range | 1.5 ~ 3pF | 2.5 ~ 6pF | 1.5 ~ 3pF |
| Adjustment Type | Top | Top | Top |
| Voltage - Rated | 25 V | 25 V | 25 V |
| Dielectric Material | Ceramic | Ceramic | Ceramic |
| Q @ Freq | 300 @ 1MHz | 500 @ 1MHz | 300 @ 1MHz |
| Size / Dimension | 0.126" L x 0.091" W (3.20mm x 2.30mm) | 0.126" L x 0.091" W (3.20mm x 2.30mm) | 0.126" L x 0.091" W (3.20mm x 2.30mm) |
| Height - Seated (Max) | 0.057" (1.45mm) | 0.057" (1.45mm) | 0.057" (1.45mm) |
| Operating Temperature | -25°C ~ 85°C | -25°C ~ 85°C | -25°C ~ 85°C |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Features | General Purpose | General Purpose | General Purpose |
