| Part Number | SFECF10M7EA00-R0 | SFECF10M7FA00-R0 | SFECF10M7GA00-R0 | SFECF10M7HA00-R0 |
|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Last Time Buy | Last Time Buy | Last Time Buy | Last Time Buy |
| Frequency | 10.7MHz Center | 10.7MHz Center | 10.7MHz Center | 10.7MHz Center |
| Impedance | 330Ohm | 330Ohm | 330Ohm | 330Ohm |
| Bandwidth | 330 kHz | 280 kHz | 230 kHz | 180 kHz |
| Insertion Loss | 3dB | 3dB | 3.5dB | 4dB |
| Filter Type | FM | FM | FM | FM |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 1412 (3531 Metric), 6 PC Pad | 1412 (3531 Metric), 6 PC Pad | 1412 (3531 Metric), 6 PC Pad | 1412 (3531 Metric), 6 PC Pad |
| Size / Dimension | 0.136" L x 0.122" W (3.45mm x 3.10mm) | 0.136" L x 0.122" W (3.45mm x 3.10mm) | 0.136" L x 0.122" W (3.45mm x 3.10mm) | 0.136" L x 0.122" W (3.45mm x 3.10mm) |
| Height (Max) | 0.055" (1.40mm) | 0.055" (1.40mm) | 0.055" (1.40mm) | 0.055" (1.40mm) |
