| Part Number | RDER72A473K1P1C03B | RDER72A473K1P1H03B | RDER72A474K1P1C03B | RDER72A473K1K1C03B |
|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Obsolete | Active | Obsolete | Obsolete |
| Capacitance | 0.047 µF | 0.047 µF | 0.47 µF | 0.047 µF |
| Tolerance | ±10% | ±10% | ±10% | ±10% |
| Voltage - Rated | 100V | 100V | 100V | 100V |
| Temperature Coefficient | X7R | X7R | X7R | X7R |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Features | - | - | - | - |
| Ratings | - | - | - | - |
| Applications | General Purpose | General Purpose | General Purpose | General Purpose |
| Failure Rate | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | Through Hole | Through Hole |
| Package / Case | Radial | Radial | Radial | Radial |
| Size / Dimension | 0.177" L x 0.124" W (4.50mm x 3.15mm) | 0.177" L x 0.124" W (4.50mm x 3.15mm) | 0.177" L x 0.124" W (4.50mm x 3.15mm) | 0.177" L x 0.124" W (4.50mm x 3.15mm) |
| Height - Seated (Max) | 0.197" (5.00mm) | 0.197" (5.00mm) | 0.197" (5.00mm) | 0.197" (5.00mm) |
| Thickness (Max) | - | - | - | - |
| Lead Spacing | 0.098" (2.50mm) | 0.098" (2.50mm) | 0.098" (2.50mm) | 0.197" (5.00mm) |
| Lead Style | Formed Leads | Formed Leads | Formed Leads | Formed Leads |
