| Part Number | NFM3DCC221R1H3L | NFM3DCC223R1H3L | NFM3DCC222R1H3L |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active |
| Capacitance | 220 pF | 0.022 µF | 2200 pF |
| Tolerance | -20%, +50% | -20%, +50% | -20%, +50% |
| Voltage - Rated | 50V | 50V | 50V |
| Current | 300 mA | 300 mA | 300 mA |
| DC Resistance (DCR) (Max) | - | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Insertion Loss | - | - | - |
| Temperature Coefficient | - | - | - |
| Ratings | - | - | - |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Package / Case | 1205 (3212 Metric), 3 PC Pad | 1205 (3212 Metric), 3 PC Pad | 1205 (3212 Metric), 3 PC Pad |
| Size / Dimension | 0.126" L x 0.049" W (3.20mm x 1.25mm) | 0.126" L x 0.049" W (3.20mm x 1.25mm) | 0.126" L x 0.049" W (3.20mm x 1.25mm) |
| Height (Max) | 0.035" (0.90mm) | 0.035" (0.90mm) | 0.035" (0.90mm) |
| Thread Size | - | - | - |
