| Part Number | LQM18DH6R8M70L | LQM18DN6R8M70L | LQM18DZ6R8M70L |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active |
| Type | Multilayer | - | Multilayer |
| Material - Core | Ferrite | - | Ferrite |
| Inductance | 6.8 µH | - | 6.8 µH |
| Tolerance | ±20% | - | ±20% |
| Current Rating (Amps) | 330 mA | - | 330 mA |
| Current - Saturation (Isat) | - | - | 120mA |
| Shielding | Shielded | - | Shielded |
| DC Resistance (DCR) | 960mOhm Max | - | 960mOhm Max |
| Q @ Freq | - | - | - |
| Frequency - Self Resonant | 40MHz | - | 40MHz |
| Ratings | AEC-Q200 | - | AEC-Q200 |
| Operating Temperature | -55°C ~ 150°C | - | -55°C ~ 125°C |
| Inductance Frequency - Test | 1 MHz | - | 1 MHz |
| Features | - | - | - |
| Mounting Type | Surface Mount | - | Surface Mount |
| Package / Case | 0603 (1608 Metric) | - | 0603 (1608 Metric) |
| Supplier Device Package | 0603 | - | 0603 |
| Size / Dimension | 0.063" L x 0.031" W (1.60mm x 0.80mm) | - | 0.063" L x 0.031" W (1.60mm x 0.80mm) |
| Height - Seated (Max) | 0.037" (0.95mm) | - | 0.037" (0.95mm) |
