| Part Number | GCJ216R71H123KA01D | GCJ216R71H223KA01D | GCJ216R71H123KA01J | GCJ216R71H123MA01D | GCJ216R71H183KA01D | GCJ216R71H153KA01D | GCJ216R71E123KA01D | GCJ216R71H103KA01D | GCJ216R71H122KA01D |
|---|---|---|---|---|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs | Not For New Designs |
| Capacitance | - | 0.022 µF | - | - | - | 0.015 µF | - | 10000 pF | - |
| Tolerance | - | ±10% | - | - | - | ±10% | - | ±10% | - |
| Voltage - Rated | - | 50V | - | - | - | 50V | - | 50V | - |
| Temperature Coefficient | - | X7R | - | - | - | X7R | - | X7R | - |
| Operating Temperature | - | -55°C ~ 125°C | - | - | - | -55°C ~ 125°C | - | -55°C ~ 125°C | - |
| Features | - | Soft Termination | - | - | - | Soft Termination | - | Soft Termination | - |
| Ratings | - | AEC-Q200 | - | - | - | AEC-Q200 | - | AEC-Q200 | - |
| Applications | - | Automotive, Boardflex Sensitive | - | - | - | Automotive, Boardflex Sensitive | - | Automotive, Boardflex Sensitive | - |
| Failure Rate | - | - | - | - | - | - | - | - | - |
| Mounting Type | - | Surface Mount, MLCC | - | - | - | Surface Mount, MLCC | - | Surface Mount, MLCC | - |
| Package / Case | - | 0805 (2012 Metric) | - | - | - | 0805 (2012 Metric) | - | 0805 (2012 Metric) | - |
| Size / Dimension | - | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - | - | - | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - |
| Height - Seated (Max) | - | - | - | - | - | - | - | - | - |
| Thickness (Max) | - | 0.024" (0.60mm) | - | - | - | 0.024" (0.60mm) | - | 0.024" (0.60mm) | - |
| Lead Spacing | - | - | - | - | - | - | - | - | - |
| Lead Style | - | - | - | - | - | - | - | - | - |
