Please send RFQ , we will respond immediately.
| Part Number | GCG31CR71E475JA01L | GCG31CR71E475KA01L | GCG31CR71E475MA01L | GCG31CR71E475JA01K |
|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active | Active |
| Capacitance | 4.7 µF | - | - | - |
| Tolerance | ±5% | - | - | - |
| Voltage - Rated | 25V | - | - | - |
| Temperature Coefficient | X7R | - | - | - |
| Operating Temperature | -55°C ~ 125°C | - | - | - |
| Features | Epoxy Mountable | - | - | - |
| Ratings | AEC-Q200 | - | - | - |
| Applications | Automotive | - | - | - |
| Failure Rate | - | - | - | - |
| Mounting Type | Surface Mount, MLCC, Epoxy | - | - | - |
| Package / Case | 1206 (3216 Metric) | - | - | - |
| Size / Dimension | 0.126" L x 0.063" W (3.20mm x 1.60mm) | - | - | - |
| Height - Seated (Max) | - | - | - | - |
| Thickness (Max) | 0.075" (1.90mm) | - | - | - |
| Lead Spacing | - | - | - | - |
| Lead Style | - | - | - | - |
