| Part Number | DE21XKY220JA3BM02F | DE21XKY220JB3BM02F | DE21XKY220JJ3BM02F | DE21XKY220JA3BM02 |
|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Obsolete | Obsolete | Obsolete | Obsolete |
| Capacitance | 22 pF | 22 pF | - | 22 pF |
| Tolerance | ±5% | ±5% | - | ±5% |
| Voltage - Rated | 250VAC | 250VAC | - | 250VAC |
| Temperature Coefficient | SL | SL | - | SL |
| Operating Temperature | -40°C ~ 125°C | -40°C ~ 125°C | - | -40°C ~ 125°C |
| Features | - | - | - | High Voltage |
| Ratings | X1, Y2 | X1, Y2 | - | X1, Y2 |
| Applications | Safety | Safety | - | Safety |
| Failure Rate | - | - | - | - |
| Mounting Type | Through Hole | Through Hole | - | Through Hole |
| Package / Case | Radial, Disc | Radial, Disc | - | Radial, Disc |
| Size / Dimension | 0.315" Dia (8.00mm) | 0.315" Dia (8.00mm) | - | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.433" (11.00mm) | 0.433" (11.00mm) | - | 0.433" (11.00mm) |
| Thickness (Max) | - | - | - | - |
| Lead Spacing | 0.295" (7.50mm) | 0.295" (7.50mm) | - | 0.295" (7.50mm) |
| Lead Style | Formed Leads | Formed Leads | - | Formed Leads |
