| Part Number | BLM21BB331SH1D | BLM21BB331SN1D | BLM21BB331SZ1D | BLM21BD331SH1D |
|---|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active | Active |
| Filter Type | Differential Mode - Single | Signal Line | - | Differential Mode - Single |
| Number of Lines | 1 | 1 | - | 1 |
| Impedance @ Frequency | 330 Ohms @ 100 MHz | 330 Ohms @ 100 MHz | - | 330 Ohms @ 100 MHz |
| Current Rating (Max) | - | 400mA | - | - |
| DC Resistance (DCR) (Max) | - | 330mOhm | - | - |
| Ratings | - | - | - | - |
| Operating Temperature | - | -55°C ~ 125°C | - | - |
| Package / Case | 0805 (2012 Metric) | 0805 (2012 Metric) | - | 0805 (2012 Metric) |
| Mounting Type | Surface Mount | Surface Mount | - | Surface Mount |
| Height (Max) | 0.057" (1.45mm) | 0.057" (1.45mm) | - | 0.057" (1.45mm) |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.079" L x 0.049" W (2.00mm x 1.25mm) | - | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Features | - | - | - | - |
