| Part Number | BLM02BX121SN1D | BLM02BX151SN1D | BLM02AX121SN1D |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active |
| Filter Type | Signal Line | Signal Line | - |
| Number of Lines | 1 | 1 | 1 |
| Impedance @ Frequency | 120 Ohms @ 100 MHz | 150 Ohms @ 100 MHz | 120 Ohms @ 100 MHz |
| Current Rating (Max) | 350mA | 280mA | 250mA |
| DC Resistance (DCR) (Max) | 500mOhm | 700mOhm | 500mOhm |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package / Case | 01005 (0402 Metric) | 01005 (0402 Metric) | 01005 (0402 Metric) |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Height (Max) | 0.009" (0.22mm) | 0.009" (0.22mm) | 0.009" (0.22mm) |
| Size / Dimension | 0.016" L x 0.008" W (0.40mm x 0.20mm) | 0.016" L x 0.008" W (0.40mm x 0.20mm) | 0.016" L x 0.008" W (0.40mm x 0.20mm) |
| Features | - | - | - |
