| Part Number | BLA2ABB121SN4D | BLA2ABB221SN4D | BLA2ABD121SN4D |
|---|---|---|---|
| Manufacturer | Murata Electronics | Murata Electronics | Murata Electronics |
| Product Status | Active | Active | Active |
| Filter Type | Signal Line | Signal Line | Signal Line |
| Number of Lines | 4 | 4 | 4 |
| Impedance @ Frequency | 120 Ohms @ 100 MHz | 220 Ohms @ 100 MHz | 120 Ohms @ 100 MHz |
| Current Rating (Max) | 50mA | 50mA | 200mA |
| DC Resistance (DCR) (Max) | 600mOhm | 900mOhm | 350mOhm |
| Ratings | - | - | - |
| Operating Temperature | -55°C ~ 125°C | -55°C ~ 125°C | -55°C ~ 125°C |
| Package / Case | 0804 (2010 Metric), Array, 8 PC Pad | 0804 (2010 Metric), Array, 8 PC Pad | 0804 (2010 Metric), Array, 8 PC Pad |
| Mounting Type | Surface Mount | Surface Mount | Surface Mount |
| Height (Max) | 0.024" (0.60mm) | 0.024" (0.60mm) | 0.024" (0.60mm) |
| Size / Dimension | 0.079" L x 0.039" W (2.00mm x 1.00mm) | 0.079" L x 0.039" W (2.00mm x 1.00mm) | 0.079" L x 0.039" W (2.00mm x 1.00mm) |
| Features | - | - | - |
