| Part Number | 46436-3005 | 46436-3007 | 46437-3005 |
|---|---|---|---|
| Manufacturer | Molex | Molex | Molex |
| Product Status | Active | Active | Active |
| Connector Usage | - | - | - |
| Connector Type | Receptacle, Female Sockets and Blade Sockets | Receptacle, Female Sockets and Blade Sockets | Plug, Male Pins and Blades |
| Connector Style | EXTreme Ten60Power | EXTreme Ten60Power | EXTreme Ten60Power |
| Number of Positions | 30 | 30 | 30 |
| Number of Positions Loaded | All | All | All |
| Pitch | - | - | - |
| Number of Rows | - | - | - |
| Number of Columns | - | - | - |
| Mounting Type | Through Hole, Right Angle | Through Hole, Right Angle | Through Hole, Right Angle |
| Termination | Solder | Solder | Solder |
| Contact Layout, Typical | 24 Signal, 6 Power | 24 Signal, 6 Power | 24 Signal, 6 Power |
| Features | Board Guide, Mating Guide | Board Guide, Mating Guide | Board Guide, Guide Pin |
| Contact Finish | Gold | Gold | Gold |
| Contact Finish Thickness | 30.0µin (0.76µm) | 30.0µin (0.76µm) | 30.0µin (0.76µm) |
| Color | Black | Black | Black |
